Model:

M8T1

Screen diagonal:

18" (460mm) diagonal

Resolution:

1280(H) x 1024(V) XGA

Pixel Pitch:

0.28(H) x 0.28(V) mm

Color depth:

16.777 million by Dithering

Contrast Ratio:

400:1(Typ)

Brightness:

200 cd/m²

View Angle:

R/L 85 / 85 U/D: 85 / 85

Signal input:

RGB Analog

Glass:

Option

Resolution Support:

VGA, SVGA, XGA, SXGA

Plug & Play:

DDC 1 / 2B

Response Time(Tr/Tf):

23ms

Audio-in(Speaker):

3W x 2

PC - IN:

15 pin D-sub

Set Color:

Silver/Black

OSD Function:

Auto adjust / Reset / Volume & Mute / Phase / Language / Channel Auto Search & Edit & Fine tune / AIR or Cable TV / Contrast / Brightness / Sharpness / Tint / Horizontal and Vertical Position

Power Consumption:

ON < 45 Watt, OFF < 5 watt

Power Adapter:

AC Input: 100-240V

Dimension:

510(H) x 425(W) x 197(D) mm

Pack Dimension:

610(H) x 612(W) x 197(D) mm

Net weight/Gross weight:

7.5Kgs / 9.8Kgs

Safety:

FCC-B / UL / TUV / GS / VCCL / CE / BSMI

ISO.:

ISO 9001 / ISO 14001

Accessory:

Adapter / AC - cord / D – SUB cable / Audio - RGB - cable / User Manual / Remote Controller

TV System Support:

NTSC / PAL / SECAM

External Connections:

VGA / S-video / Video-in (AV-in) / YcbCr / TV Tuner
