Lead-Acid Battery

Design 15 years Series

¡@

Specification

 Design 15 years series
Model No. Nominal
Voltage
(V)		 Nominal
Capacity
(AH)		 Dimensions¡]mm¡^ Dimensions(in) Weight
(Approx.)		 Termainal
Length Width Height Overall
Height		 Length Width Height  Overall
Height		 Kg Ib
SB2-200 2 200 173 109 330 364 6.81 4.29 12.99 14.33 14.00 30.86 F10
SB2-300 2 300 171 151 330 364 6.73 5.94 12.99 14.33 19.50 42.99 F10
SB2-350 2 350 171 151 330 364 6.73 5.94 12.99 14.33 20.50 45.19 T10
SB2-400 2 400 210 176 330 367 8.27 6.93 12.99 14.45 26.50 58.42 T10
SB2-450 2 450 210 176 330 367 8.27 6.93 12.99 14.45 27.50 60.63 T10
SB2-500 2 500 241 171 330 365 9.49 6.73 12.99 14.37 31.50 69.45 T10
SB2-600 2 600 302 175 330 367 11.89 6.89 12.99 14.45 39.00 85.98 T10
SB2-800 2 800 410 175 330 367 16.14 6.89 12.99 14.45 54.00 119.05 T10
SB2-1000 2 1000 475 175 330 367 18.70 6.89 12.99 14.45 64.00 141.10 T10
SB2-1500 2 1500 400 350 345 382 15.75 13.78 13.58 15.04 100.00 220.46 T10
SB2-2000 2 2000 490 350 345 382 19.29 13.78 13.58 15.04 128.00 282.19 T10
SB2-3000 2 3000 710 350 345 382 27.95 13.78 13.58 15.04 197.00 434.31 T10

Features
1.  Sealed Maintenance Free
Peakpower's unique design and sealing technique guarantees that no electrolyte leakage can occur from the terminals or case of any Powergor Battery Tech. co., ltd.. The sealed system eliminates electrolyte checking and water addition.
2.  Long Shelf life and storage
Special vents, high purity lead and grid alloys assure a low self-discharge rate and consequently a long shelf life. Lower storage temperatures enhance shelf life characteristic even further.
3.  High quality and firm reliability
Peakpower batteries can keep the stable and reliable capacity. It also can withstand overcharge, over discharge, vibration and shock. It is also capable of extended storage
4.  Standby use
The float service life, or life expectancy under continuous float charge at 2.25vpc at 20 deg is 5 years for batteries up to 26ah and 10 years for batteries with capacities greater than 30ah.
5.  Cyclic use
The number of charge/discharge cycles depends on the capacity taken from the battery (a function of discharge rate and depth of discharge) operating temperature and charging method.
6.  Easy Installation
Batteries are easily installed in a dry and vented place; meanwhile it can be put by the rack to use safely.
7.  compact design
Peakpower batteries utilize state of the art design, highest grade materials, and a carefully controlled plate making process to provide excellent output per cell.
8.  designed-in reliability
Cutting edge manufacturing and process control combined with strict quality assurance procedures guarantee consistent and dependable performance.
9.  Low Self-Discharge
Because of the use of Lead Calcium grids alloy, Peakpower VRLA battery can be stored for long periods of time without recharge.
10.  Wide operating temperature range
Charge: -15 to 50¢J
Discharge: -15 to 60¢J
Storage: -20 to +50 (in fully charged condition)

Applications:
  • UPS systems
  • Telecommunications equipment
  • Emergency lighting
  • Fire and burglar alarm systems
  • Access control devices
  • Electronic equipment require memory protecting
  • Solar powered systems

¡@

¡@

¡@
