Laptop Computer

PS-530A (10.2)  Series

　

PS-530A Series

OLATEK product introduction will provide accurate information as far as possible . The pictures on this introduction may have subtle differences from the real model.  Effect demo map and diagram are for reference only:

　

Detailed parameter description of PS-530A series

　

Hardware and software device	Performance description	Hardware software disposition	Performance description
Processor	Intel Atom N270(533FSB)	Chip set	Intel945GES+ICH7
Processor Frequency	1.60GHZ	VGA Card	Intel GMA950 VGA Card
Memory	DDR2 /1G-2G/667	Audio	Stereo Audio2.0
Internal HDD	2.5Inch 80-320G/SATA8	Operating system	WINDOWS XP,VISTA
Extended storage  and MB	SD card(1GB-16GB)	Network support type	10/100MHigh Speed Ethernet Card
	USB and hard disk
Screen Size	10.2"TFT Digital screen 1366*768WXGA		Wireless network card802.11A/B/G)
Controls	Keyboard and Touchpad
DC Power	AC110-240V,DC18.5,3.5A
Battery	3core batteries11.1V/2200MAH(may elect 6core batteries4400MAH)	Interface	3 USB2.0 Interface
Headset Specifications	3.5"(Built-in microphone)		1 POWER Interface
USB	USB1.1,USB2.0		1 MIC SPEAKER jack
Keyboard	Standard 86 keyboards		1 3IN1 card Interface
Built-in speaker specification	Built-in 0.5W*1 three-dimensional loudspeaker		Network Interface
Status Light	System work power light		1Security Lock Interface
	Number lock indicating lamp	Camera	Built-in 1.3 million pixel  camera
	AC110-240V,DC18.5,3.5A	Power	Bellow 35W
	Trundle locking indicating lamp	Blue tooth	BLUETOOTH optional function modules
standby time	2-3 Hours	Language	Support multi-language
size	260MM*180MM*32.5MM	Color	White \ Black \pink\yellow
shell color	Pink black white yellow	Weight	1.3KG(Including battery)
Accessories	Adapter、battery、driver CD  、manual、warranty card
